Asrock B760M-HDV/M.2 D4 Intel B760 LGA 1700 micro ATX
Kod: PLYASR1700048
Dostava sljedeći dan
Na bilo koje mjesto
Garancija isporuke
Neoštećena roba
Preko 3.000 mjesta točenja
Po cijeloj Hrvatskoj
Detaljan opis proizvoda
Nema dostupnog opisa proizvoda
Dodatni parametri
| Kategorija: | Motherboards Socket-1700 |
|---|---|
| Težina: | 0.78 kg |
| EAN: | 4710483942020 |
| Maximum number of SMP processors: | 1 |
| Processor socket: | LGA 1700 |
| Processor manufacturer: | Intel |
| Compatible processor series: | Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i3, Intel® Core™ i5 |
| HDCP: | Yes |
| Parallel processing technology support: | Not supported |
| Audio output channels: | 7.1 channels |
| Windows operating systems supported: | Windows 10 Education x64, Windows 11 x64 |
| Motherboard form factor: | micro ATX |
| Audio chip: | Realtek ALC897 |
| Motherboard chipset family: | Intel |
| Motherboard chipset: | Intel B760 |
| Certification: | - FCC, CE - ErP/EuP ready (ErP/EuP ready power supply is required) |
| Unbuffered memory: | Yes |
| Memory channels: | Dual-channel |
| Supported memory clock speeds: | 3200, 4400, 5333 MHz |
| Memory slots type: | DIMM |
| Supported memory types: | DDR4-SDRAM |
| Maximum internal memory: | 64 GB |
| Number of memory slots: | 2 |
| ECC сompatibility: | Non-ECC |
| Width: | 244 mm |
| Depth: | 201 mm |
| Ethernet LAN: | Yes |
| Ethernet interface type: | Gigabit Ethernet |
| LAN controller: | Realtek RTL8111H |
| Wi-Fi: | No |
| EPS power connector (8-pin): | Yes |
| Chassis intrusion connector: | Yes |
| CPU fan connector: | Yes |
| ATX Power connector (24-pin): | Yes |
| TPM connector: | Yes |
| Number of SATA III connectors: | 4 |
| USB 2.0 connectors: | 3 |
| Front panel connector: | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 2 |
| BIOS type: | UEFI AMI |
| Cables included: | SATA |
| RAID levels: | 10, 0, 5, 1 |
| RAID support: | Yes |
| Supported storage drive interfaces: | M.2, SATA III |
| Number of storage drives supported: | 6 |
| Microphone in: | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 3 |
| HDMI ports quantity: | 1 |
| DisplayPorts quantity: | 1 |
| DisplayPort version: | 1.4 |
| Line-in: | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: | 1 |
| VGA (D-Sub) ports quantity: | 1 |
| Ethernet LAN (RJ-45) ports: | 1 |
| PS/2 ports quantity: | 1 |
| USB 2.0 ports quantity: | 2 |
| PCI Express x16 (Gen 4.x) slots: | 1 |
| PCI Express x1 (Gen 3.x) slots: | 2 |
| Number of M.2 (M) slots: | 2 |
| Warnings: | Before starting any maintenance or installation, disconnect the product from the power supply., Avoid direct contact with electronics to prevent electrostatic damage., Do not dispose of the motherboard in the ordinary rubbish bin; the product requires special disposal. |
