GIGABYTE B650 AORUS ELITE AX ICE Motherboard - Supports AMD Ryzen 9000 CPUs, 12+2+2 Phases Digital VRM, up to 8000MHz DDR5 (OC), 1xPCIe 5.0 + 2xPCIe 4.0 M.2, Wi-Fi 6E, 2.5GbE LAN, USB 3.2 Gen 2x2
Kod: PLYGIGAM50017
Dostava sljedeći dan
Na bilo koje mjesto
Garancija isporuke
Neoštećena roba
Preko 3.000 mjesta točenja
Po cijeloj Hrvatskoj
Detaljan opis proizvoda
Nema dostupnog opisa proizvoda
Dodatni parametri
| Kategorija: | Motherboards Socket-AM5 |
|---|---|
| Težina: | 1.994 kg |
| EAN: | 4719331859374 |
| Warranty period: | 3 year(s) |
| Supported processor sockets: | Socket AM5 |
| Maximum number of SMP processors: | 1 |
| Processor socket: | Socket AM5 |
| Processor manufacturer: | AMD |
| Compatible processor series: | AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series |
| Maximum resolution: | 4096 x 2160 pixels |
| DirectX version: | 12.0 |
| HDCP: | Yes |
| Parallel processing technology support: | Not supported |
| Audio output channels: | 7.1 channels |
| PC health monitoring: | Fan, Water cooling, Temperature, Voltage |
| Motherboard chipset family: | AMD |
| Product colour: | White |
| Audio chip: | Realtek ALC897 |
| Motherboard form factor: | ATX |
| Motherboard chipset: | AMD B650 |
| Power source type: | ATX |
| Cooling type: | Passive |
| Windows operating systems supported: | Windows 10 x64, Windows 11 x64 |
| Supported memory clock speeds: | 6800, 5200, 6200, 6666, 6600, 6400, 4400, 5600, 7200, 6000, 4800 MHz, 7000, 7600 MHz, 7800, 8000 |
| Maximum internal memory: | 256 GB |
| Unbuffered memory: | Yes |
| Supported memory types: | DDR5-SDRAM |
| Memory channels: | Dual-channel |
| Number of memory slots: | 4 |
| Memory slots type: | DIMM |
| ECC сompatibility: | Non-ECC |
| Maximum internal memory per slot: | 64 GB |
| Supported memory clock speed (max): | 8000 MHz |
| Depth: | 244 mm |
| Width: | 305 mm |
| Height: | 35 mm |
| Bluetooth: | Yes |
| LAN controller: | Realtek RTL8125 |
| Ethernet LAN: | Yes |
| Wi-Fi: | Yes |
| WLAN controller model: | Realtek RTL8852CE |
| Ethernet interface type: | 2.5 Gigabit Ethernet |
| Bluetooth version: | 5.3 |
| Wi-Fi standards: | Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax), 802.11b, Wi-Fi 4 (802.11n), 802.11g |
| Top Wi-Fi standard: | Wi-Fi 6E (802.11ax) |
| Front panel audio connector: | Yes |
| Number of SATA III connectors: | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) connectors: | 1 |
| USB 2.0 connectors: | 2 |
| Front panel connector: | Yes |
| TPM connector: | Yes |
| Number of chassis fan connectors: | 4 |
| CPU fan connector: | Yes |
| RGB LED pin header: | Yes |
| ATX Power connector (24-pin): | Yes |
| Peripheral (Molex) power connectors (4-pin): | 1 |
| EPS power connector (8-pin): | Yes |
| 12V power connector: | Yes |
| Number of CPU fan connectors: | 2 |
| Number of RGB LED pin headers: | 4 |
| USB 3.2 Gen 2x2 connectors: | 1 |
| Number of water pump connectors: | 2 |
| Number of EPS power connectors (8-pin): | 1 |
| Clear CMOS jumper: | Yes |
| BIOS type: | UEFI AMI |
| Desktop Management Interface (DMI) version: | 2.7 |
| Package depth: | 270 mm |
| Package width: | 335 mm |
| Package height: | 80 mm |
| Package weight: | 2.33 kg |
| Antenna included: | Yes |
| Screws included: | Yes |
| Batteries included: | Yes |
| Bundled software: | Norton® Internet Security (OEM version) LAN bandwidth management software |
| RAID support: | Yes |
| Supported storage drive interfaces: | M.2, SATA III |
| Supported storage drive types: | HDD & SSD |
| RAID levels: | 10, 0, 1 |
| Number of storage drives supported: | 7 |
| Number of HDDs supported: | 4 |
| DisplayPorts quantity: | 1 |
| Ethernet LAN (RJ-45) ports: | 1 |
| DisplayPort version: | 1.4 |
| HDMI version: | 2.1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: | 2 |
| Headphone outputs: | 1 |
| WiFi-AP antenna jack: | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: | 5 |
| HDMI ports quantity: | 1 |
| Microphone in: | Yes |
| Line-in: | Yes |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: | 1 |
| USB 2.0 ports quantity: | 4 |
| PCI Express x16 (Gen 3.x) slots: | 2 |
| PCI Express x16 (Gen 4.x) slots: | 1 |
| Number of M.2 (M) slots: | 3 |
| 1st M.2 highest PCI Express generation: | 5.0 |
| 3rd M.2 largest key size: | 25110 |
| 2nd M.2 highest PCI Express generation: | 4.0 |
| 1st M.2 largest key size: | 25110 |
| 2nd M.2 largest key size: | 25110 |
| 3rd M.2 highest PCI Express generation: | 4.0 |
| Battery technology: | Lithium-Manganese Dioxide (LiMnO2) |
| Number of battery cells: | 1 |
| Battery type: | CR2032 |
| Lithium weight per battery: | 0.07 g |
| Battery weight: | 3 g |
| Country of origin: | China |
| Products per shipping (inner) case: | 1 pc(s) |
| Warnings: | Avoid contact with liquids to prevent electronic damage., Dispose of in accordance with local regulations for electronic waste., Do not disassemble to avoid damage to internal components and loss of warranty. |
